Automatic Box Strapping Machine Manufacturer:

Automatic Box Strapping Machine Manufacturer: Specification

Type
Fully Auto Box Strapping Machine

Material
Industrial

Capacity
1200 Pcs/hr

Computerized
No

Automatic Grade
Automatic

Control System
Frequency Speed Control

Cutting Thickness
12 Millimeter (mm)

Strapping Speed
1.5 m/s

Selection Mode
Automatic

Dimension (L*W*H)
800X 600 X800 Millimeter (mm)

Color
Silver

Weight (kg)
100 Kilograms (kg)

Warranty
1 Year

Automatic Box Strapping Machine Manufacturer: Trade Information

Minimum Order Quantity
1 Number

Supply Ability
50 Per Month

Delivery Time
1 Week

Certifications
iso

About Automatic Box Strapping Machine Manufacturer:

We are an established organization of this domain engaged in the manufacturing and exporting of precisely-engineered Fully Auto Box Strapping Machine. Used for tying up cartons and boxes, these machines find application in variegated industries. These machines are known amongst our clients for high speed, accurate functionality and resistance to wear & tear. We provide timely delivery of Fully Auto Box Strapping Machine in tamper-proof packaging to ensure safe transit.

Further Details:

This machine is in particular intended and engineered for completely automatic strapping with active roller on the workbench, which makes it appropriate for use in a binding line for handing articles of a variety of sizes and in uneven and asymmetrical shapes. It can comprehend complete unmanned procedure by combining a power transmit line / production line
The size and weight of the article to be packaged can be fabricated in accordance with the needs and requirements of the end customers. Further more, the driven unit prepared with dust cover and agrees to an exceptional design, which facilitates and makes possible silent yet influential operation. The machine also has the mechanical power off utility, which in turn put aside electric energy
Style of binding : Single and multiple-strip corresponding binding, complimentary selection from 1 strip to 4 strips by means of photoelectric control.

Technical Specifications:

Power Supply:110V 220V 380V 50Hz 60Hz
Strapping speed:26times per min
Dispenser flange:Coil core ID. 200-280mm
Strapping article size:min. W260 X H30mm
Sealing style:Heat-melt
Tension N:May-80
Table height:700-840mm
Suit strap PP or PE:Width: 8, 9, 10, 12, 12.7, 15.5, 18, 19mm
Dimension LX W X H :W1629X L700 X H1566 mm
Net weight:315kgs
Gross weight:350kgs
What can be adjusted:Arch size, strap width, power supply, strap core ID

An automatic box strapping machine is an industrial packaging device designed to automatically wrap, tension, and heat-seal Polypropylene (PP) straps around cartons or packages without manual intervention. These high-speed machines, often used in production lines, feature conveyor systems, adjustable tension, and electronic controls, operating typically at 2.5 seconds per cycle.

Key Technical Specifications

Strapping Speed: 2.5 seconds per cycle.
Strap Width: Typically 6mm - 15mm.
Tension Force: Adjustable, generally ranging from 5 kg to 90 kg.
Power Supply: 220V/440V, Single or 3-Phase, 50/60 Hz.
Arch Size (Inner): Standard sizes often around

800mm600mm800 mm cross 600 mm

800mm600mm (W x H).

Sealing Method: Heat Sealing
Dimensions: Approximately 14001600mm Length, 600-800mm Width.
Machine Weight: Ranges from 100 kg to over 300 kg.

Key Features & Components

Automatic Operation: Uses sensors to detect boxes, eliminating manual feeding and sealing.
Control System: Often equipped with an advanced PCB or PLC for reliability.
Safety Features: Emergency stop buttons and protective guards.
Structure: Durable powder-coated mild steel or stainless steel frame.
Applications: Ideal for pharmaceutical, food, logistics, and manufacturing industries.
